AC Power SST 400a 480v Main Disconnect Type 3R Outdoor Rated
The SST Series of Portable Camlock Disconnects by AC Power Distribution provide safe and convenient main disconnect and overcurrent protection for any temporary power distribution system. All Portable Camlock Disconnects are built to the highest standards utilizing the quality components and features of the SST Series product line, fully UL Listed, and backed by AC Power Distribution's manufacturer warranty.
Features:
-100% continuous-duty main breaker on all models, ranging from 100A to 400A.
-Electronic trip prevents nuisance tripping associated with typical thermal breakers and high ambient temperatures.
-The 400A & 250A models have adjustable over-current settings for protection of various feeder circuits. Access cover to overcurrent setting can be sealed in your facility or left open for adjustments on location.
-Self-closing cover protects main breaker.
-Unique combination ground is compatible with both reverse and straight ground distribution systems.
-Three 20A convenience outlets with 100% continuous-duty, branch-rated breakers provide quick and easy utility power without the hassle of taps and adapters. *Available with or without GFCI receptacles. (Except 480V version)
-Indicator lights for all inlets and outlets, and metering test jacks provide a safe and easy check on power status.
-Recessed receptacles, indicator lights & circuit breakers prevent damage to components.
-Flow-thru design keeps feeder cable and branch circuits in the same direction reducing cable clutter.
-Stackable compact size w/top and side mounted handles and feet for convenient portability and orientation.
-Rugged, heavy duty anodized aluminum enclosure and stainless steel hardware is resistant to corrosion and wear.
-Guard straps can be ordered in your choice of available colors to easily identify your equipment.
-UL Listed and labeled to UL1640 Portable Power-Distribution Equipment.
400A 480v Main Disconnect (Adjustable 160A thru 400A)
Type 3R Outdoor Rated
Phase & Amperage
400A 277/480V 3/o, Suitable for use on: 480V 3/o,**
Input Type - Flow Thru
5-wire Camlock w/Covers
Output Type
(1) Circuits 5-wire Camlock w/Covers
Voltage Meter Test Jacks
Circuit Protection
160A-400A 277/480V 3/o, - (1) 400A 3-pole Electronic Trip Breaker (25k AIC) Adjustable over-current from 160A - 400A
Dimensions & Weight
23"L x 13"W x 11"H - 60 lbs.
