Lex 400 Amp Hammerhead™ Cam Splitter Weather Resistant

Part No: DB400N1J4AJ2CC-63

400 Amp Hammerhead™ Cam Splitter Weather Resistant

400A 120/208Y VAC, (1) Set of (5) 16 Series Cam-type, Single Pole Males (Inlets) to (4) Sets of (5) 16 Series Cam-type, Single Pole Receptacles (Outlets) and (2) NEMA 5-20 (Edison) Straight Blade Receptacles (Outlets), Hammerhead™

- This Hammerhead™ portable power distribution box breaks 400 Amp, 3 Phase, 4 Pole, 5 Wire power into (4) sets of 100 Amp, 3 Phase, 4 Pole, 5 Wire overcurrent protected circuits to power shelters, live events and other portable distribution units
- The (2) NEMA 5-20, 20 Amp duplex receptacles provide convenient power for lights, fans and light tools
- Heavy-duty molded rubber enclosure is fully insulated and resistant to shock, impact and corrosion
- Breakers mounted under hinged window for easy access and enhanced safety
- Compact for convenient portability
- Elevated base keeps receptacles above ground level

Features & Benefits‍ ‍

• Heavy duty molded rubber enclosure is fully insulated, resistant to shock, impact, corrosion and weather

• Extremely compact for convenient portability

• Meets NEC requirements for properly rated branch circuit protection when downsizing cable

Specifications‍ ‍

• Enclosure: HAMMERHEAD

• Rating: 400 Amp, 3 Ø, 120/208 VAC, 4P 5W

• Input:
  (5) 16 Series Cam-type male devices‍ ‍

• Output: (4) 100 A, 3 Ø, 120/208 VAC, 5 Wire 16 Series Cam-type female devices (2) NEMA 5-20, 20 A, 2P3W, 125 VAC duplex receptacles ‍

• Overcurrent Protection: (4) 100 A, 3-Pole Branch Circuit Rated Breakers (2) 20 A, 1-Pole Branch Circuit Rated Breakers ‍

• Overall Dimensions: 15" L x 18" W x 22" H ‍

• Weight: 75 lb ‍

• Enclosure Type: NEMA 3R Weatherproof
