Lex 30A Tail Input Bento Enclosure to (6) 20A Circuits
Sale Price:$963.99 Original Price:$1,391.45
sale
Part No: BNB3-3B
Lex 30A Tail Input Bento Enclosure to (6) 20A Circuits
30 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, Bento Enclosure, NEMA L21-30, 30 Amp locking plug on 12 inch 10/5 SOW-A tail to (6) 20 Amp circuits with (3) NEMA 5-20, 20 Amp color-coded duplex receptacles, NEMA 1 Indoor
Fed from 30 Amp power, this box provides NEMA 5-20, 20 Amp household type receptacles for lights, audio equipment and tools for a wide range of applications.
Features & Benefits
30 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, Bento Enclosure, NEMA L21-30, 30 Amp locking plug on 12 inch 10/5 SOW-A tail to (6) 20 Amp circuits with (3) NEMA 5-20, 20 Amp color-coded duplex receptacles, NEMA 1 Indoor
Fed from 30 Amp power, this box provides NEMA 5-20, 20 Amp household type receptacles for lights, audio equipment and tools for a wide range of applications.
Features & Benefits
- Stackable and compact for easy storage
- Heavy duty extruded engineered thermoplastic enclosure is electrically insulated, resistant to shock, impact and corrosion
- Breakers are mounted flush for easy access and circuit identification
- Collapsible handle and end plate grips for easy handling in tight spaces
- Hydraulic magnetic breakers will not nuisance trip at higher temperatures
Specifications
- Rating: 30 Amp, 3 Phase (H, H, H, N, G), 4 Pole, 5 Wire, 120/208Y VAC
- Environmental Rating: NEMA 1 Indoor
- Input: (1) NEMA 21-30, 30 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC locking plug on 12 inch 10/5 SOW-A tail
- Output: (3) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC color-coded duplex receptacles split wired for (6) 20 Amp circuits
- Feed Thru: None
- Overcurrent Protection: (6) 20 Amp hydraulic magnetic branch circuit rated breakers
- Dimensions: 11.5" L x 5.9" W x 7.6" H
- Approximate Weight: 6.5 lbs.
